• Precizion HALO offers accurate low-level illuminance switching, reducing energy usage
• Available with pre-programmed part night Off and part night Dimming, featuring automatic daylight
  saving (DLS) or GMT adjustment
• Heavy Duty option available (impact resistance)

• Contemporary compact design to complement today’s modern light fittings
• Simple insert, rotate and lock mounting feature, no tooling needed and single-handed operation to install
• Safe extra low voltage (SELV) product
• Protected from mains-borne surges
• Reflective PCB, shielding components from heat stress

Sensor:

Sensor: Photo IC

Switching Technology:

Switching Technology: SR

Switching Regime in Lux and Time:

35 Lux / 18 Lux: Yes

20 Lux / 2o Lux: Yes

10 Lux / 10 Lux: Yes

Switching Ratio: 1:1 or 1:0.5

Switching Delay: 10 seconds

Load:

Maximum load for LED lighting: Rating as per LED driver

Supply and Consumption:

Voltage: SELV (typically 16v)

Surge Suppression: Protected by the LED driver

Frequency: Not Applicable

Consumption in Watts: SR lower tier

UMSUG Charge Code: Not Applicable

Operating Temperature:

Min / Max operating ambient temp range: -20 / +80°C

IP Rating: IP66

Warranty: 10 years

Compliance Standards:

BS5972, BS EN IEC 55015, BS EN 60529, BS EN IEC 6100-3-2, EN 6100-3-3, BS EN IEC 61000-4-2, BS EN IEC 61000-4-3, BS EN 61000-4-4, BS EN 61000-4-5, BS EN 61000-4-6, BS EN IEC 61000-4-11, BS EN 61547

• Zhaga compatible connector system – 4 pole contacts
  o Pin 1: Not utilised
  o Pin 2:
  o Pin 3:
  o Pin 4: Not utilised
• IK09 option (dome)
• Hot pluggable capable
• IP66 Compliant
